MINI PC ASUS RYZEN 7

Model Name                  PN52-BB7000XTC-ARG

OS                       W/O OS

CPU                    AMD Ryzen™ 7 5800H Processor, 3.2 GHz (20M Cache, up to 4.40 GHz)

Chipset                            Integrated

Graphics                         Integrated - AMD Radeon™ Graphics

Memory                           W/O RAM; supports 2 x SO-DIMM DDR4 3200 MHz memory slots (up to 32GB*2)

Storage                            W/O Storage; supports (3) internal storage drives:

                            2 x M.2 2280 PCIe Gen3x4, supports 256GB~1TB NVMe™ SSD and

                            1 x 2.5" SATA 6Gb/s, supports 1TB 7200rpm 7mm HDD

Wireless Network                       Mediatek MT7921, Wi-Fi 6, Bluetooth 5.2, 2*2

LAN                    1 x Realtek® RTL8125B-CG, 2.5G LAN

Wake On Lan support                Wake on from S3

                            Wake on from S4/S5, need BIOS setting

Optical Drive                  N/A

Integrated Speaker                     N/A

Audio                  2 channels supported

Card Reader                   N/A

TPM                    TPM 2.0 chip

Chassis Intrusion Detection                  N/A

HDMI CEC        Onboard            Yes, the leftmost HDMI is supported

              Configurable Port         N/A

Interface           Front I/O            1 x USB 3.2 Gen1 Type-C

                            2 x USB 3.2 Gen1 Type-A

                            1 x Audio Jack (Line out/Mic in/Headphone out)

              Side I/O             1 x Kensington Lock slot

              Rear I/O             1 x USB 3.2 Gen2 Type-C (with DisplayPort 1.4/PD-in*)

                            1 x USB 3.2 Gen2 Type-A

                            2 x USB 3.2 Gen1 Type-A

                            2 x HDMI 2.1 (up to 4K@60Hz)**

                            1 x Configurable Port (COM)

                            1 x 2.5G RJ45 LAN

                            1 x Padlock Ring

                            1 x DC-in

                            "* Supports up to 3 displays simultaneously (Type-C + 2 x HDMI)

* Power supply device needs to support Power Delivery & at least 100W output

** The leftmost HDMI port supports CEC"

Physical             Dimension        120 x 130 x 58 mm (0.9L)

              Weight 0.75 kg (barebone)

Power Supply                 20Vdc/19Vdc, 6.0A/6.32A 120W Power Adapter

Accessories                   VESA Mount / Power Adapter
